READY FOR EACH
OF YOUR PROJECTS...
Our steel structures were first used in 2014. Exposteel was officially incorporated in the first half 2016, thus being the young member of the
group. Our team is headed by Petr Krejčí who, during his twenty years of experience in expo and event management, participated in orders that included custom-built steel structures for clients like Peugeot in Paris and Frankfurt, Wargaming. net in Cologne (years 2013 - 2016), ESET in Hannover, etc. He is also the one who personally manages the progress and implementation of each project.
Production of custom-built steel / aluminum structures according to EU standards.
The structure analysis in any language is included.
Structural surveys
– Construction of exhibition displays
– Roof structures, roof beams, buildings, halls
– Glass elements
Optimisation of construction design
Processing of project documentation of surveyed structures
Reviews of static calculations for foreign exhibition areas
Testing of construction elements and whole construction units in authorised lab
Static survey of structures:
STEEL – in accordance with EC 3
WOODEN – in accordance with EC 5
ALUMINUM – in accordance with EC 9
GLASS – in accordance with DIN 18008:2010–12
Assessment of single-layered, laminated and insulating glass
standardized or original
single or two-storey
small or large – from 25 to 300 m2
Dimensions:
Standard dimensions of the construction module – 4.5 x 4.5 m
Floor height: 3200 mm
Staircase width from 1 to 2.5 m
The minimum size of the area is 25 m2
What we can arrange for you:
Architectural design
Technical documentation
Structural analysis
Approval of the two-storey construction by the exhibition administration
Turn-key exhibition solution – including all required equipment
Modular segments:
Supporting beams
Columns – jäkl 200 x 200 x 8 mm
Visible railing – stainless steel pipes 60 x 4 mm (Komaxit)
Railing for cladding – stainless steel profiles
60 x 60 x 5 mm, Jäkl 70 x 70 x 5 mm
Handrails – stainless steel pipes 50 mm
Stringers: two types of stringer height:
– 160 x 280 mm – 19 stairs
– 180 x 260 mm – 17 stairs
Two-flight stairs with landings:
– 160 x 280 mm – 9 and 10 stairs
The components are made of S235 steel.
Cladding of the structure can be made of particle boards, laminated particle boards, plasterboards or OSBs.
Various designs of railings – glass panels, steel coloured panels or particle boards.
Fully equipped assembly teams from 4 to 40 persons. Every team has its own team leader with English / German language knowledge.
Our assembly team is fully equipped with all necessary tools. We arrange for our transport and accomodation. Occupational safety and health are an inevitable part of each assembly worker ́s training – safety shoes, safety vest and safety helmet are a matter of course.
We work at most exhibition centres in Europe – Munich, Berlin, Paris, Sien, Madrid, Moscow, Prague, Hannover, Rome, and in the world – Johannesburg, Singapore, Vancouver, Rio de Jainero, Shanghai, Bangkok.
